Trim Panels
|
Wired Trim Panel
|
|
- Military spec rocker switches
- Sealed and waterproof
- No exposed screws
- Powdercoated aluminum
- Panel size: 3 3/4" W x 3 3/4" H
Panels are not available in chrome.
When ordering please specify panel color and switch cover colors.
Click here for Livorsi Marine Pricing (PDF)
|
Four things you will need to know when ordering your mechanical indicator:
- How many slots or positions do you want to monitor? - how many drives, tabs, etc.
- Is it a Livorsi, Mercury Actuator or a #6 drive? - The actuator used will determine the layout of the card
- Where will the cables enter the indicator? -
Bottom is standard, but it can be top or horizontal (port or starboard)
- What length of 33 series cable do you need? - Measure the actual route the cable will take. Cables come in 2 ft increments, from 10 ft to 36 ft
|
|
Wired Trim Panels |
| Description |
Part Number |
| 1 drive, 2 tabs |
TP1D2T |
+ panel color |
| 2 drives |
TP2D |
| 2 drives, override |
TP2DO |
| 3 drives |
TP3D |
| 2 tabs |
TP2T |
| 2 tabs, override |
TP2TO |
| Then specify switch cover colors |
|
|
Trim Panels |
| Description |
Part Number |
| 1 drive, 2 tabs |
UTP1D2T |
+ panel color |
| 2 drives |
UTP2D |
| 2 drives, override |
UTP2DO |
| 3 drives |
UTP3D |
| 2 tabs |
UTP2T |
| 2 tabs, override |
UTP2TO |
| Then specify switch cover colors |
|
|
